Heat Tunnel - Midi Series T-60

Heat Tunnel - Midi Series T-60

Heat Tunnel - Midi Series T-80

$11,995.00

The Maripak Midi Series - Heat Tunnels are a must-have quality built heat shrink tunnel system.. Maripak’s entry into their standard medium size line of heat tunnels are designed for fully-automatic superior film shrink performance where consistent and constant heat levels are prime considerations.

Built to the same exacting high standards as all of their higher-end wrappers and equipment, these versatile tunnels are heavy-duty units that run with precision and temperature accuracy capable of shrinking many pieces.  The Midi Series is a top circulated airflow system.

System estimates depend on sealer speeds, product size, and film type
when combined with the proper Maripak sealing equipment and infeed.

The Midi Series Heat Tunnel T-80 is easy to use and rugged enough for constant and consistent operation where extreme control and accurate film shrink is a must.

Check out our current inventory here... See Our Live Inventory Feed

Pricing shown below is for a standard base model with no options. Stocked Inventory Equipment Prices may be higher and vary based on the added options / upgrades in each unit.
See below for specific specification details and information. Configure and build your own machine with options by request.

Availability: In stock
SKU
47261

Custom notifications:

This model is typically in stock ready to ship.Request a quote by the "Get A Quote" button along with adding any options, customization's and specific comments needed. A budgetary e-quote

If out of stock, unit can be back-ordered to fill any orders. Unit will be built to order with a lead-time TBD.

MIDI TUNNEL SERIES - T-80 - HEAT SHRINK TUNNEL - MODEL # T80

Maripak’s entry into their standard medium size line of tunnels are designed for fully-automatic superior shrink performance applications where medium size, consistent and constant heat levels are prime considerations for users.  Built to the same exact high standards as all of their higher-end equipment, these versatile units are capable of shrinking many pieces. System estimates depend on sealer speeds, product size, and film type when combined with the proper sealer and infeed.

The MIDI Series T-80 is easy to use and rugged enough for constant and consistent operation on a daily basis while taking up minimal space.

They come standard with premium features not available on most competitive models in this price range including embedded heat chamber, easy operation controls, touchscreen library to easily recall package setups, and a double-layer isolation room.

The Maripak’s exclusive Hands-on Design makes these units the most user-friendly and energy-efficient tunnel on the market today. World-Wide approved brands for all mechanical and electrical components make the MIDI SERIES T-80 as popular with maintenance staffs as with operators.

When your application calls for an automatic and superior film shrink performance tunnel capable of fully-automatic operation, Maripak’s MIDI Series offers the lowest total-cost-in-operation available today with the most advanced and evolved technologies.

All PARTS are stocked and available for immediate shipment. All technical support, service, and machine and equipment parts are fully supported by our dedicated technical Service Support and Parts fulfillment location in the Greater Tampa FL area.

* Additional MIDI Series models are available for various size products, see our other models as well in this MIDI Tunnel Series.

Technical Specifications

  • Series: T80 - 900 - Single Chamber
  • Installed Power: 220-240 V - 3 Phase
  • Consumption (Max / Average):  13 kW / 8 kW
  • Compressed Air Supply: No - No air required -
  • Tunnel Door Height (D): 10" - (250mm)
  • Conveyor Belt Width (E): 31" - (800mm)
  • Mobility: Yes - Casters with brake
  • Working Height (H1): 34" - (860mm)
  • Color: Customized - Mixed Gray
    RAL7015 + RAL7010
  • Dimensions (GxAxH): 56" x 55" x 68"
    - (1420 x 1400 x 1725mm)
  • Palletized Size (GxAxH): 62" x 62" x 74"
    - (1575 x 1575 x 1880mm)
  • Weight (Net / Gross): 617 lbs / 701 lbs
    - (208 kg / 318 kg)

* For DIN A4 form and MIDI TUNNEL Series real working speed depends on the product dimensions and film type.

Advantages:

  • Compact sleek new " PRO " design
  • Easy to integrate due to casters with brakes into any production line directly
  • Full automation with inline conveyor
  • Adds to a non-stop packaging operation for faster production speeds
  • Built for reduced energy consumption in mind
  • Easy to use, compatible with health and safety standards for operator safety

Features:

  • Flexibility for automatic and semi-automatic packaging lines
  • POF, PE, PVC films tested and approved for applications as needed
  • Reduced energy consumption by double-layered isolation room design
  • Series is a specially designed top circulated airflow heat system
  • Top embedded heat chamber and fan system for non-operator access
  • Perfect dissipated heat inside via adjustable flaps and channels
  • Conveying speed control to optimize heat treatment duration to package
  • Automatic cool down to 165 degrees F / 70 degree C before switch off
  • Additional emergency temperature control system against fire risk
  • PID controlled accurate heat adjustment for easy operation
  • Circulation fan speed control to optimize airflow rate per application
  • Additional air circulation control by side flap handles
  • User-friendly color touch screen operation control panel
  • Easy to integrate with all types of packaging machines directly
  • Long-lasting covered tunnel non-making conveyor spindles
  • Up-to-date safety electric and mechanical measures of CE directives
  • Color: Metallic Dark Gray ( RAL code - customized mixture )

Safety Measures:

  • In-feed and discharge points of the tunnels metal protection shields are applied to remove contact to high-temperature surfaces
  • Conveyors stop automatically during jams to avoid further problems or additional internal issues
  • Mechanism against high temperature or fire risk in case of conveyor and fan circulation stops, heaters are isolated immediately
  • Tunnel fans are protected with mesh guards for operator safety and protection
  • Heaters have been isolated in the closed heating chamber, and can not be reached by the operator in daily use

Optional:

  • Alternative conveyor types: Wire Mesh, Teflon Mesh, Plastic Mesh
  • Higher Chamber and frame designs are available
  • Ironing rolls at discharge for side smoothing of PE wrapped packages
  • PTFE bracelet applied conveyor rods for centering round shaped products
  • PE cooling fan at discharge for fast cool-down of PE wrapped packages
  • Exhaust gas hood can be applied if required by application
  • Stainless steel versions are available for wet / moist working environments
  • Record-able heat and speed via touch panel controller

Quality:

  • ISO9001 quality standards with the relevant norm's confirmation
  • CE certifications comply with the latest CE directives
  • World-wide approved brands for all mechanical and electrical components
  • 3-year warranty for non-wearable parts against manufacturing defects or faults
  • Warranty extendable by 1-year increments for an additional cost
  • Wearable parts are not included in warranty terms
  • 1 set of wear parts is provided along with the machine if applicable
  • 5 year spare part availability is provided






All Maripak machines and equipment are fabricated to the highest ISO 9001 standards and requirements

Additional Information and Resources


Price:

  • The machine shown is a base unit with no options or custom additions. Price provided above is for Budgetary reasons only.
  • Options and or Custom additions can be provided upon request and a custom quote will be provided by our Sales Support Group or an authorized distributor
  • The Online Prices may be used for general budgetary pricing purposes only and may differ slightly and are subject to change.
  • Firm pricing necessary to place any order must be confirmed with a formal quotation through the normal Maripak USA - RFQ / quote process along with the proper assignment of an authorized distributor.
  • Product designations starting with " B " are ( Built-to-Order ) items which are already engineered machines or equipment, but built individually to order.


Videos and Additional Content:

    • See all the Maripak USA equipment in action in a host of different applications by visiting our







    • Real production applications running on ever-evolving premium industrial shrink equipment that provides ROI


Qualifications:

    • Qualified for Government Section 179 Tax Deduction machine or equipment purchases and financing
    • Machine and equipment leasing and financing options are available through Maripak USA's preferred finance partner


Check the available Finance Options


Drawings and Dimensions:




Series Sizes and Specifications:


    Custom notifications:

    This tunnel may have a lead-time associated with it. One of our machine agents will advise based on the specific model #, options, and or customization of your machine. A specific lead-time will be provided at that time.

    " Add to Quote " for a personalized e-quote.

    More Information
    SKU 47261
    Short Description

    The Maripak Midi Series - Heat Tunnels are a must-have quality built heat shrink tunnel system.. Maripak’s entry into their standard medium size line of heat tunnels are designed for fully-automatic superior film shrink performance where consistent and constant heat levels are prime considerations.

    Built to the same exacting high standards as all of their higher-end wrappers and equipment, these versatile tunnels are heavy-duty units that run with precision and temperature accuracy capable of shrinking many pieces.  The Midi Series is a top circulated airflow system.

    System estimates depend on sealer speeds, product size, and film type
    when combined with the proper Maripak sealing equipment and infeed.

    The Midi Series Heat Tunnel T-80 is easy to use and rugged enough for constant and consistent operation where extreme control and accurate film shrink is a must.

    Check out our current inventory here... See Our Live Inventory Feed

    Pricing shown below is for a standard base model with no options. Stocked Inventory Equipment Prices may be higher and vary based on the added options / upgrades in each unit.
    See below for specific specification details and information. Configure and build your own machine with options by request.

    Custom note

    This model is typically in stock ready to ship.

    Request a quote by the "Get A Quote" button along with adding any options, customization's and specific comments needed. A budgetary e-quote

    Additional Info This machine ships direct from the Greater Tampa Florida area and will be PLUS FREIGHT. Freight will be quoted and depend on the delivery zip code.

    *** Special Custom Creating will be made to ensure the safe and secure shipment of the machine and will be added to the final cost of the machine as each machine's crating is different. ***
    Manufacturer Maripak
    Manufacturer's SKU MAR-MID-T80
    Manufacturer's Model Number MID-T80
    Manufacturer Category Heat Tunnels - Shrink Tunnels
    Unit of Measure each
