The Maripak - LMC-P Series Semi-Automatic - L-Bar Sealer is an excellent machine for long oversized products. Maripak’s solution to long and over-sized products in the standard line of sealers are designed for L-seal applications where larger oversized and longer products are prime considerations.
Typically larger product are overlooked for simple L-sealer applications, the LMC " P " is a simple and heavy-duty large-sized pneumatic actuated L-sealer to cover that overlooked area.
Built to the same exacting standards as their high-speed wrappers, these versatile units are capable of wrapping many pieces per minute when combined with the proper infeed or motivated manual operator.
The LMC-P model 14065 is easy to use and rugged enough for constant operation.
See below for specific specification details and information. Configure and build your own machine with options by request.
Availability:In stock
SKU
46904
Custom notifications:
Request a quote by the "Get A Quote" button along with adding any options, customization's and specific comments needed. A budgetary e-quote will be sent to you within minutes.
If out of stock, unit can be back-ordered to fill any orders. Unit will be built to order with a lead-time TBD.
LMC-P SERIES - SEMI-AUTOMATIC - L-SEALER - MODEL # 14065-P
Maripak’s solution to long products in the standard line of sealers are designed for L-seal applications where larger oversized and longer products are prime considerations in a small to a medium-sized user. Built to the same exacting standards as their high-speed wrappers, these versatile units are capable of wrapping many pieces per minute depending on size and film typewhen combined with the proper infeed or manual operator.
The 14065-P is easy to use and rugged enough for constant operation on a daily basis while taking up very little space.
They come standard with premium features not available on most competitive models in this price range including low-mount film cradle, easy operation controls, touchscreen library to easily recall package setups, and automatic dwell time compensator.
The Maripak’s exclusive Hands-on Design make these units the most user-friendly L-Sealer units on the market today. World-Wide approved brands for all mechanical and electrical components make the 14065-P as popular with maintenance staffs as with operators.
When your application calls for an L -seal wrapper capable of semi-automatic operation with larger oversized and longer products, Maripak’s 14065-P series offers the lowest total-cost-in-operation available today.
All PARTS are stocked and available for immediate shipment. All technical support, service, and machine and equipment parts are fully supported by our dedicated technical Service Support and Parts location in the Greater Tampa FL area.
Technical Specifications
Seal Bar Opening: 10" - (250mm)
Maximum Capacity: 4 - 6 packs / minute *
Maximum Product Height: 10" - (245mm) - standard
Maximum Roll Diameter: 10" - (250mm)
Working Height (D): 34" - (860mm)
Compressed Air Supply: 4 - 6 Bar
Film Types: POF: 7-37 micron / PVC: 15-25 micron
Color: Light Gray RAL7035
Working Principle: Pneumatic
L-Sealer Sizes: 55" x 26" - (1400 x 650mm)
Maximum Film Width: 28" - (700mm)
Installed Power: 220V - 24 Amp - 3 Phase
Consumption (Max / Average): 2,2 kW / 0,7 kW
Dimensions (AxBxC): 49 x 123 x 65" - (1250 x 3130 x 1650mm)
Palletized Size (AxBxC) :57 x 131 x 67" - (1450 x 3330 x 1700mm)
Weight (Net / Gross): 2028 lbs / 2293 lbs - (920 kg / 1040 kg)
* For DIN A4 form and LMC-P Series servo real working speed depends on the product dimensions and film type.
* Possible Electrical output options avaiable by request for an upcharge.
Advantages:
A practical solution for long products at low/ medium-capacity requirements
Ability to provide heat to wire at exact efficient doses, realized by the I-Sealing System ®
Ability to keep wire temperature constant, realized by the I-Sealing System ®
Increase in sealing quality, process accuracy, and life-span by stabilizing heat control
Easy to use, compatible with health and safety standards
Minimized layout requirement due to compact single-chassis design
Cold temperature operation as low as 30 degrees F, anything below application should be confirmed
Features:
Point-wise equal L-Bar pressure controlled by a double pneumatic cylinder
Simultaneously triggered two separate buttons for two hands to justify operator safety
Easy to integrate with all types of heat tunnels directly
Products are easily discharged by internal belt conveyor automatically
Position of the working table can be adjusted with respect to the product width
Single-axis film roll holding profile can be easily removed, replaced and fixed
Easily transportable on wheels inside a facility
Operated by a digital control panel
Sealing:
Sealing is actuated pneumatically in between the wire and silicon rubber
Sealing wire is positioned on the top frame in order to increase efficiency
Sealing wire is embedded into heat-resistant fiber profile
Teflon belt covered rubber increases sealing quality and life-span of silicon
Flexibility:
Discharge belt height of the conveyor can be adjusted with respect to varying product height
Discharge belt working time of conveyor can be adjusted with respect to varying product length
Power of sealing wire can be adjusted with respect to varying film thicknesses
Heat, time and speed parameters can be easily adjusted via the digital control panel
Various language options are available in the digital control panel
Detailed technical menu is available in the digital control panel
Optional:
Automatic Trim Winder option is available upon request - add $1600 for option
Foot Pedal option is available upon request - add $650 for option
Height Chamber Change-out - Maximum Product height up to 13.5" (35cm) - add $1695 for option
Optional Voltage / Amperage Configurations Available for and upcharge - inquire
Stainless steel versions are available for wet/moist/damp working environments - inquire
Regular sealing wire can be upgraded to solid L-Knife for thicker film sealing needs - inquire.
Heat-treated strong wooden case is available for transportation needs - inquire
On-site installation and training service options are available for a fee
Quality:
ISO9001 quality standards with the relevant norm's confirmation
CE certifications comply with the latest CE directives
World-wide approved brands for all mechanical and electrical components
3-year warranty for non-wearable parts against manufacturing defects or faults
Wearable parts are not included in warranty terms
1 set of wear parts is provided along with the machine
5-year spare part availability is provided
All Maripak machines and equipment are fabricated to the highest ISO 9001 standards and requirements
Additional Information and Resources
Price:
The machine shown is a base unit with no options or custom additions. Price provided above is for Budgetary reasons only.
Options and or Custom additions can be provided upon request and a custom quote will be provided by our Sales Support Group or an authorized distributor
The Online Prices may be used for general budgetary pricing purposes only and may differ slightly and are subject to change.
Firm pricing necessary to place any order must be confirmed with a formal quotation through the normal Maripak USA - RFQ / quote process along with the proper assignment of an authorized distributor.
Product designations starting with " B "are ( Built-to-Order ) items which are already engineered machines or equipment but built individually to order.
Videos and Additional Content:
See all the Maripak USA equipment in action in a host of different applications by visiting our
Real production applications running on ever-evolving premium industrial shrink equipment that provides ROI
Qualifications:
Qualified for Government Section 179 Tax Deduction machine or equipment purchases and financing
Machine and equipment leasing and financing options are available through Maripak USA's preferred finance partner
This machine will have a lead-time associated with it. One of our machine agents will advise based on the specific model #, options, and or customization of your machine. A specific lead-time will be provided at that time.
